Q20 Bus & Minibus Driver Seat

Availability:
Quantity:
Q20 Bus & Minibus Driver Seat
Q20 Bus & Minibus Driver Seat
Q20 Bus & Minibus Driver Seat
Q20 Bus & Minibus Driver Seat
Q20 Bus & Minibus Driver Seat


Q20

Q20


Q20 driver's seat is a high-grade gasbag driver's seat, mainly used in bus、minibus and trucks. The Q20 driver's seat from high-grade driver's seat specially designed for large luxury buses. The seat chassis is equipped with a pneumatic damping and balancing system and a pneumatic lifting system, which can effectively reduce harmful vibrations, reduce fatigue and enhance driving safety. The seat backrest is equipped with lumbar support adjustment and side air pocket adjustment, and can be equipped with optional ventilation, heating, massage and other comfort features to meet the driver's various comfort requirements, thus enabling the driver to better operate safely.



Type of seat:

Q20

Security Certification:

CQC2011011114471311

Cushion width:

500mm

Backrest width:

500mm

Backrest height:

890mm

Backrest adjustable angle:

80°-135°

Human body weight adjustment range:

50KG-120KG

Shock absorbing mechanism travel range:

0-50mm

Cushion height adjustment range:

0-100mm

Cushion tilt angle adjustment range:

-3°-9°

Cushion depth adjustment range:

0-50mm

Horizontal front and rear adjustment range:

0-270mm

Quick exhaust function:

Pneumatic Lumbar Support:

Safety belts:

Three-point seat belt with alarm function


Adjustable armrests:

Heating function:

Ventilation function:

Massage function:

Base for mounting:

Can be customized according to the body

Cover:

Can be customized according to your needs


You can also choose from the following special services:

◆ We can develop and design products according to your needs

◆ We can provide outsourced processing services for seat-related parts and semi-finished products

◆ We can provide seat skeleton, sponge, cover and other semi-finished products for sale
